全自动装盒机，是机电一体化的高科技产品，完全符合GMP要求。该机由产品输送带、产品吸放机构、自动下说明书机构、自动打码机构和纸盒包装机组成，最高运转速度可达120盒/分，我公司根据各种产品的生产设备设计与装盒机联接的进料机构方便用户高效、节约化管理。
Automatic packing machine, is a mechanical and electrical integration of high-tech products, in full compliance with GMP requirements. The machine is made up of product conveyor belt, product suction and release mechanism, automatic instruction mechanism, automatic coding mechanism and carton packaging unit, the maximum operating speed can reach 120 boxes/min, our company according to the production equipment of various products design and the feeding mechanism connected with the carton machine is convenient for users to manage efficiently and economized.
主要特点：无料不下盒，避免有空盒的现象，无说明书自动剔除，盒舌上能够自动打印钢印，变换规格方便快捷，特别适用于规格众多的产品。
Main features: no material no box, to avoid the phenomenon of empty boxes, no manual automatically eliminated, the box tongue can automatically print steel marks, easy to change specifications, especially suitable for many specifications of products.
本机广泛用于制药、食品、日化等众多领域的包装。如：制药的固体制剂（片剂、胶囊剂等）产品的泡罩装盒，膏状、乳脂、胶体产品软膏的装盒，用于西林瓶、安培瓶、注射器的托盘式的装盒，用于液体、固体药品的瓶式装盒；用于粉末和颗粒产品的袋式装盒等。食品类的各种形式的袋式装盒,各种灌装、盒装的装盒，甜品、巧克力、糖果、饼干、瓶装式酒类、冷冻制品的装盒等。日化类的膏状、乳脂、洗液、胶体产品软管或袋装式、瓶状的装盒，牙膏、肥皂制品的装盒,电灯泡、计算机软盘、胶带卷、摄影胶卷等各形式装盒。
This machine is widely used in pharmaceutical, food, daily chemical and many other fields of packaging. Such as: pharmaceutical solid preparations (tablets, capsules, etc.) product blister box, paste, cream, colloidal product ointment box, for the cillin bottle, ampere bottle, syringe tray box, for liquid, solid medicine bottle box; It is used for bagging of powder and pellet products. Various forms of bag packing of food, all kinds of filling, box packing, dessert, chocolate, candy, cookies, bottled wine, frozen products, etc. Daily chemical paste, cream, lotion, colloidal products hose or bag type, bottle box, toothpaste, soap products box, light bulb, computer floppy disk, tape roll, photographic film and other forms of packaging.
|
序号 |
名称 |
单位 |
数值和说明 |
备注 |
|
1 |
整机外形尺寸 |
mm |
长1400*宽1100*高1500 |
|
|
2 |
装盒机总功率 |
KW |
1.3 |
|
|
3 |
工作电压 |
V |
380 |
|
|
4 |
装盒速度 |
盒/分 |
40-120（稳定速度） |
根据物料大小及难易度 |
|
5 |
适合纸盒规格 |
长/宽/高 |
（50-180）x（30-85）x（15-50） |
可加大 |
|
6 |
纸盒纸质 |
g |
300-350白卡 |
每平方 |
|
7 |
耗气量 |
L/min |
5-20 |
|
|
8 |
压缩空气 |
Mpa |
0.5-0.8 |
|
|
9 |
总重量 |
kg |
880 |
|
|
10 |
噪声 |
≦dB |
75 |
|
|
11 |
说明书 |
70g |
L(80-260)xW（80-160） |
每平方 |
|
12 |
|
|
|
|
