No. |
Item |
Technical data |
|
|
1 |
Blanking frequency |
10-65 times/min，1-5 sheet/times （travel scope: >80 blister depth: >10） |
|
|
2 |
Capacity |
Calculating with standard sheet: 9600sheet/hours （4 sheet/times，blanking frequency: 40time/min） |
|
|
3 |
Adjustable scope of feed travel |
Standard:10-140mm，the max scope 150mm |
|
|
4 |
Sheet specification |
Standard: 80 mm×57mm Reference: 80×57, 95×65, 103×43, 120×43 Designed as the customers’ requirement, and the max size: 270×110mm |
|
|
5 |
The max forming area and depth |
270mm×150mm×28mm |
|
|
6 |
Wrapper |
Composite Alu film |
Length: 250mm, thickness: 0.11-0.15mm |
|
PVC |
Length: 250mm, thickness: 0.15-0.5mm |
||
|
PTP |
Length: 250mm, thickness: 0.02-0.35mm |
||
|
Dialysis paper |
Length:250mm, specification: 50-100 gram: |
||
|
Inside diameter of wrapper scroll |
70-76mm |
||
|
7 |
Power of heating |
Forming heating |
1.5KW |
|
Heat-sealing |
1.5KW |
||
|
8 |
Main motor power |
1.5KW |
|
|
9 |
Power supply |
380V 50Hz |
|
|
10 |
Capacity of air compressor (provide for oneself) |
≥0.2m3/min Pressure: 0.4～0.6MPa |
|
|
11 |
Mould cooling |
** supply: 60L/h |
|
|
12 |
Overall dimension |
Whole |
3345mm×635mm×1560mm |
|
Fission |
1670mm×635mm×1560mm 1675mm×635mm×1560mm |
||
|
13 |
Weight |
1500Kg |
|
