The effective width of packaging material： |
280mm |
|
Guide roller width： |
280mm（Aluminum alloy material） |
|
Aluminum Aluminum working speed： |
15 cuttings/min～40cuttings/min |
|
Aluminum Plastic working speed： |
15cuttings/min～55cuttings/min |
|
Machine max working speed： |
60cuttings/min |
|
PVC max diameter： |
φ300mm |
|
PTP max diameter： |
φ250mm |
|
Aluminum foil max diameter： |
φ300mm |
|
Waste collection max diameter： |
φ400mm |
|
Cold forming(ALU ALU)forming stretch area and depth： |
250mm×100mm×12mm（Beyond the area and the depth is determined according to the customer requirements）； |
|
PVC forming area and depth： |
250mm×100mm×13mm （ Beyond the area and the depth is determined according to the customer requirements）； |
|
Servo motor control stepless adjustable stroke ： |
10mm ～ 120mm （ Beyond above stroke,according to the customer requirements）； |
|
Air volume flow： |
≥0.36m3/min |
|
Total machine power： |
380V、50Hz、4KW（ALU ALU power）； 380V、50Hz、7KW（ALU PVC power） |
|
Equipment split size(mm)： |
15.① 1850mm×650mm×1650mm ② 1700mm×900mm×1900mm |
|
Packing size(mm): |
3900×1100×2000 |
|
Machine net weight： |
2T |
